60V 100Ah CLF OEM ODM Lifepo4 Lithium Battery Pack for Electric Tricycle Rickshaw Sightseeing Bus Golf Cart Low Speed Cars etc.
Battery Parameters
Rated voltage: 60.8V
Rated capacity: 100Ah
Energy: 60.8kWh
Cell type: Lithium Iron Phosphate (LiFePO4)
Battery cell specifications: 3.2V 100Ah
Number of cells: 16 series 4 parallel (19S1P)
Discharge rate: 1C (continuous), 3C (peak)
Charging rate: 0.5C
Cycle life: ≥3000 times (80% DOD)
Working temperature: -20℃ ~ 60℃
Protection level: IP65
Size: 650*370*230m
Weight: 60KG
Battery Details
PRODUCT LIST
| Battery type | Voltage(V) | Capacity(AH) | Size(H*W*T) | Weight(KG) |
| LiFePO4 | 48V | 52AH | 400*350*200mm | 20.38KG |
| LiFePO4 | 48V | 75AH | 400*350*200mm | 34.32KG |
| LiFePO4 | 48V | 100AH | 500*400*200mm | 41.18KG |
| LiFePO4 | 48V | 120AH | 500*400*200mm | 47.84KG |
| LiFePO4 | 48V | 150AH | 600*500*200mm | 53.66KG |
| LiFePO4 | 48V | 200AH | 600*500*260mm | 74.88KG |
| LiFePO4 | 48V | 300AH | 600*500*260mm | 14.40KG |
| LiFePO4 | 60V | 52AH | 400*350*200mm | 25.48KG |
| LiFePO4 | 60V | 75AH | 500*400*200mm | 42.90KG |
| LiFePO4 | 60V | 100AH | 600*500*200mm | 51.48KG |
| LiFePO4 | 60V | 120AH | 600*500*200mm | 59.80KG |
| LiFePO4 | 60V | 150AH | 600*500*200mm | 67.08KG |
| LiFePO4 | 60V | 200AH | 600*500*260mm | 93.60KG |
| LiFePO4 | 60V | 300AH | 650*550*260mm | 143.00KG |
| LiFePO4 | 72V | 52AH | 400*350*200mm | 30.58KG |
| LiFePO4 | 72V | 75AH | 500*400*200mm | 51.48KG |
| LiFePO4 | 72V | 100AH | 600*500*200mm | 61.78KG |
| LiFePO4 | 72V | 120AH | 600*500*200mm | 71.76KG |
| LiFePO4 | 72V | 150AH | 600*500*200mm | 80.50KG |
| LiFePO4 | 72V | 200AH | 600*500*260mm | 112.32KG |
| LiFePO4 | 72V | 300AH | 650*550*260mm | 171.60KG |
Product Features:
1. Lighter weight, smaller size.
2. High temperature performance.
3. Extremely safe, no explosion, no fire under collision.
4. Strong over-discharge resistance and charge retention.
5. Strong charging acceptance and quick-charging capability.
6. Maintenance-free and no acid or water for maintenance in usage.
7. Large capability and long life for all high power output applications.
8.Environmentally friendly non-toxic, non-contaminating, no rare metal.
9. Low self-discharge and good discharge performance at low temperature.
10. Excellent large current discharge performance especially in startup and climbing.
FAQs
Q1. Are you a factory?
A: Yes, we are a professional lithium battery manufacturer in China, and factory tour is acceptable.
Q2. Do you accept OEM/ODM?
A: Yes, OEM, ODM, LOGO, and STICKER is acceptable, our professional team is on hand to offer you any solutions.
Q3. Can I have a sample order first?
A: Yes, sample order is acceptable.
Q4. How will my order be shipped?
A: Chalong Fly offers a variety of shipping methods, such as DHL, UPS, FedEx, TNT, Airline and sea shipping.
Q5: What kind of certificates do you have?
A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.
Q6. Can we sign a NDA in order for a long-term cooperation?
A: Yes, the client’s requirements is respected.
Q7. Why do you choose Chalong Fly?
A: Chalong Fly R&D center has more than 100 R&D engineers, 25 of whom have more than 10 years of experience related to power development. We have a deep understanding of power electronics technology, and a full understanding of the needs of the application industry, and have developed many public technology solutions.
Contact us for more informations!
